BARDpole 2.4 "LONG"

This antenna is the collaboration between TrueRC and BARD. It is a planar bazooka dipole antenna for TBS Tracer receiver, IRC Ghost or other 2.4 GHz systems. This end fed dipole is designed to get the most range out of your control link by retaining an uniform radiation pattern.

Introducing the TrueRC BARDpole 2.4 GHz Antenna

Durable and flexible planar bazooka dipole antenna with 8cm flexible cable and lockable U.fl for extra safety.



The antenna uses a thin, flexible and durable PCB. Crashing inverted? No problem, the antenna will flex out of the way.



The bottom 2cm is inert and can be used for mounting from the base allowing maximum exposure of the antenna.





Specifications:

•


• Gain: 2.2dbi


• Bandwidth: 2300MHz-2500MHz


• Weight: 1.3g


• Size: 180mm x 9mm


• Connector: U.fl with 200mm line.





Useful print!

•


• Swivel holder


• Ball adaptor


• Holder for ball adaptor


• FR7 mount


• FR7 mount 2


• iFlight Titan DC7 mount


• iFlight Chimera7 mount


• Project 399 Super G mount


• GepRC Mark4 mount


• BigFoot 10" LR mount


• Hyperlow RS mount
