X-AIR 5.8 MK II for HDzero Goggles — installed view
zoom_out_map
chevron_left chevron_right

X-AIR 5.8 MK II pair for HDzero goggles

TrueRC X-AIR 5.8 MK II pair for HDzero goggles. Slide onto the goggles rails and screw on the custom knurled SMA connectors. 10 dBic gain, 120° beam per antenna combining to 135° total. Low profile 15mm design.

  • RHCP
  • LHCP
  • Combo Stubby
  • Pair
  • Combo Core

$89.99

89.99 Tax excluded

check In stock
X-AIR 5.8 MK II for HDzero Goggles — front view
X-AIR 5.8 MK II pair for HDzero goggles View all variants
89.99 Tax excl.
check In stock
Description

TrueRC X-AIR 5.8 MK II pair for HDzero goggles. Simply slide the antennas onto the goggles' rails and screw on the custom knurled SMA connectors. 10 dBic gain combined with a 120° beam width yields excellent long-range performance in a compact, low-profile package. Pair with singularity stubby or CORE omni-directional antennas for a complete antenna system.

Low profile — only 15mm thick

The most compact antenna at this gain level. The included slide-on mounts attach natively to the HDzero goggles rails.

Custom knurled SMA connectors

Made to the highest standards to fit HDzero goggles perfectly. Knurled finish for easy hand-tightening.

Specifications
  • Bandwidth: 5.1GHz–6.7GHz
  • Gain: 9.5–10.5 dBic
  • Polarization: RHCP or LHCP
  • Beam-width*: 120°
  • Beam-width @-3dB**: 68°
  • Connector: SMA male
  • Dimensions: 32mm × 32mm × 15mm
  • Weight: [À COMPLÉTER]

*Coverage where reception is at least equivalent to an omni.
**Coverage where at least 70% of the max range is obtained.

Data sheet
0608597254488
0608597254488
Frequency (GHz)
5.8
Type of polarization
Circular polarization
Compatibilities
HD Zero Google
Connector
SMA
